Accumulation table
Accumulation table for temporary storage
Suitable for: Bulk goods, rotationally symmetrical parts
capacity: low buffer capacity
execution: Design tailored to the specific requirements of each customer
- Description
- Advantages
- Technical data
- Media
Accumulation tables, also known as rotary storage tables, are an efficient solution for the short-term buffering of various types of products. They are particularly useful where production or packaging speeds vary, manual downstream processes are involved, or sensitive parts need to be stored gently. Typical applications include behind packaging machines, in the food industry, or for feeding delicate turned parts for further processing.
A classic example is the use of an accumulation table behind a pouch packaging machine. Here, packaged food products are transferred to the turntable surface and from there manually processed at a packing station. Since the employees at these packing stations are often also occupied with logistical tasks, there is a need for short-term, organized intermediate storage to ensure continuous production. The rotary storage tables here function as an ergonomic buffer zone, preventing products from falling on top of each other and ensuring they are always easily accessible. MTF rotary accumulation tables are available in various designs that can be individually tailored to the product, the application, and the environmental requirements. A particularly hygienic option is the rotary table made entirely of stainless steel. The materials and design meet the highest hygiene standards and are easy to clean – ideal for applications involving food or in cleanrooms. For sensitive plastic or metal parts, such as turned parts with delicate surfaces, a rotary table with a PE turntable surface is recommended. This surface ensures that the components are protected upon contact with the table and are not damaged or scratched. Another special type is the accumulation table with a spiral attachment, which is used, for example, when a strict FIFO (First In First Out) buffering strategy must be observed. In this case, the components to be buffered are stacked sequentially along the spiral. Regardless of the design, all accumulation tables are equipped with a high-torque geared motor, which, in combination with frequency control, allows for precise adjustment to the required conveying or buffering speed. This enables optimal coordination with the upstream machine or with the rhythm of manual workstations. The stable and height-adjustable base ensures a secure stand and an ergonomically sound working height – an important criterion for continuous use. MTF accumulation tables are characterized by their high quality and versatility. Whether as a simple buffer behind a packaging machine, as a gentle intermediate storage area for sensitive components, or as a hygienic accumulation table in food processing – they offer a well-designed, durable, and adaptable solution for smooth material flows in a wide variety of industries.
Transfer of packaged food items onto a turntable surface and from there manually to a packing station
Robust construction for industrial use
Flexibly adaptable to customer-specific requirements
Space-saving integration into existing systems is possible
Easy cleaning thanks to smooth surfaces
Compatible with various conveyor systems
Feature
Value
diameter:
800 / 1,000 / 1,250 / 1,250 / 1,500 / 1,750 / 2,000 mm
Turntable material:
stainless steel
Turntable support material:
Stainless steel smooth / Stainless steel 5WL / Stainless steel 6WL / PE 1000 green / PE 1000 natural
Side guide:
without / fixed / moving
Infiltration:
without / with
Expulsion:
without / with
scraper:
without / with
Direction of rotation:
clockwise / counterclockwise
Drive power:
87 / 250 W
speed:
2.8 / 7.0 / 10.4 min-1
